Cargo cantilever lift

Cargo cantilever lift

The TAF-LIFT cargo cantilever lift is a type of lifting equipment designed to lift and move cargo to a height or existing floors. It is characterized by a design where the platform or cargo cabin moves along a console or mast.

This type of lift requires a supporting (bearing) wall or column to which it will be attached, since this type of lift is not self-supporting and stable.

Cantilever cargo lift manufactured by TAF-87

№	Name	Characteristic
1	Carrying capacity	up to 2,500 kg
2	Lift height	up to 50 meters
3	Occasion	electromechanical/chain|hydraulic
4	Power consumption	0.75-7.0 kW
5	Other	Individual

Prices for TAF-LIFT cargo cantilever lifts:

№	Name	Characteristic load capacity	Price, UAH
1	ПВ-2-3-6-250-Е-У2	up to 250 kg	from 160 000
2	ПВ-2-3-1-1000-Е-УХЛ1	up to 1 200 kg	from 310 000
3	ПВ-3-5-5-2500-Е-У2	up to 2,500 kg	from 490 000
4	Individual	Individual	Contractual

TAF-LIFT cargo console lifts are important tools for effective and safe work with cargo at height and in difficult conditions.

The TAF-87 enterprise produces TAF-LIFT cargo console lifts in the workshop using a sheet metal bending machine, guillotine, cutting and cutting machines, which reduces the number of welding areas and increases the quality of the product. Welding is performed semi-automatically, protective coatings are applied by air.

Delivery is negotiable. The flight of a 7-ton vehicle with a manipulator in Kharkiv, taking into account unloading, is 800 UAH/hour. By road or along the ring road 30 UAH/km in each direction. Depending on the quantity of products, the price may vary both in the higher and lower directions.

The term of manufacturing of the PTO is from 10 to 60 working days.

The TAF-87 enterprise provides a guarantee for the PTO for 12 months.
